Flexel ECOFOIL Under Laminate Aluminium Foil Heating Mat
Flexel ECOFOIL Under Laminate Aluminium Foil Heating Mat
Price includes VAT Shipping calculated at checkout.
The Flexel ECOFOIL Under Laminate Aluminium Foil Mat is an electric underfloor heating mat for floating laminate and engineered wood floors in special locations where carbon infrared heating film cannot be used, such as bathrooms and shower rooms (special locations as defined in BS 7671). Each mat is a fluoropolymer heating cable encased in aluminium foil, 500 mm wide, with a heat output of 140 W/m², a 3 m cold tail and a 10-year guarantee.
The aluminium foil spreads the heat evenly across the floor and acts as an earthed grid, which is what makes the mat suitable for these locations. XPS thermal insulation board and a thermostat are available as optional extras below.
Features
- Quick installation: roll out the mat and fix it to the insulation board
- For floating laminate and engineered wood floors
- Fully earthed aluminium foil, suitable for special locations such as bathrooms and shower rooms
- Dry installation: no self-levelling compound needed
- Low build height: only 7 mm together with the XPS thermal insulation board
- 3 m cold tail on every mat
- 10-year guarantee
Optional extras
What else you need
XPS thermal insulation board. The mat must be laid on XPS Thermal Insulation Board. It stops heat being lost into the subfloor and is also the underlay for the flooring. It must cover the full room area, wall to wall, so order the full floor area plus about 10% extra for waste and cutting.
Thermostat. Each room or heating zone needs one 16A thermostat with a floor sensor. In bathrooms the thermostat must be fitted outside the room and set to control by the floor sensor only.
Both can be added with the tick boxes next to the price. If you're not sure what you need, send us a floor plan and we'll work it out for you.
Where to use it
ECOFOIL is made for special locations (as defined in BS 7671) such as bathrooms and shower rooms, where carbon infrared heating film must not be installed. The earthed aluminium foil makes it suitable for these rooms. It is designed for floating laminate and engineered wood floors, but is not suitable under laminate with metal clip locking systems. In bathrooms the thermostat must be fitted outside the room, and the mat must be controlled by the floor sensor only. Installation must be carried out by a qualified electrician.
Specifications
| Product | Flexel ECOFOIL Under Laminate Aluminium Foil Mat (EF140 range) |
| Construction | Advanced fluoropolymer heating cable encased in aluminium foil |
| Operating voltage | 230 V, 50 Hz |
| Heat output | 140 W/m² |
| Mat width | 500 mm |
| Sizes | 1 to 14 m² |
| Cold tail length | 3 m |
| Build height | About 7 mm including the XPS insulation board |
| Guarantee | 10 years |
